High-performance thermoplastic valves engineered for pressure, reliability, and longevity.
HDPE Ball Valves
Overview
Cosmoind’s HDPE Ball Valves are precision-engineered using in-house mold designs and advanced manufacturing. Built from PE4710 / PE2708 / PE100 / PE80, they deliver superior strength, chemical resistance, and long-term durability.
Fully pressure-rated
Lightweight and impact-resistant
Environmentally friendly
Ideal for gas, water, and industrial systems
Product Advantages
Unique Body-Ball and Ball Seat Structure for long-term pressure stability.
Side-Cut Patent Design reduces operating torque by 48%.
Optimized Ball Seat Surface for enhanced sealing and durability.
Full-Port Flow Path
maintains flow rate and minimizes pressure loss.
Anti-Ball Push Prevention System ensures stability under pressure.
Foreign Matter Filtration and leak-tight performance.
Technical Specifications
Material
Bimodal High-Density Polyethylene (HDPE)
Size Range
- ½” IPS to 8” IPS (Standard Type)
- 8” IPS to 16” IPS (Gear Box Type)
SDR
11 (other SDRs available on request)
Pressure Ratings
| SDR | PE4710 for Industrial | PE4710 for Gas | |||
|---|---|---|---|---|---|
| 73.4°F | 100°F | 120°F | 140°F | 73.4°F | |
| 11 | 200 psi | 156 psi | 126 psi | 100 psi | 125 psi |
| 17 | 125 psi | 98 psi | 79 psi | 63 psi | 80 psi |
| SDR | PE2708 for Industrial | PE2708 for Gas | |||
|---|---|---|---|---|---|
| 73.4°F | 100°F | 120°F | 140°F | 73.4°F | |
| 11 | 160 psi | 124 psi | 100 psi | 80 psi | 100 psi |
| 17 | 100 psi | 78 psi | 63 psi | 50 psi | 62.5 psi |
| SDR | PE4710 for Industrial | PE100 for Gas | |||
|---|---|---|---|---|---|
| 20°C | 30°C | 40°C | 50°C | 20°C | |
| 11 | 16 bar | 13.6 bar | 11.68 bar | 10.08 bar | 10 bar |
| 17 | 10 bar | 8.5 bar | 7.3 bar | 6.3 bar | 6.25 bar |
| SDR | PE2708 for Industrial | PE80 for Gas | |||
|---|---|---|---|---|---|
| 20°C | 30°C | 40°C | 50°C | 20°C | |
| 11 | 12.5 bar | 10.62 bar | 9.12 bar | 7.87 bar | 8 bar |
| 17 | 8 bar | 6.8 bar | 5.84 bar | 5.04 bar | 5 bar |
Temperature Range
20°C – 50°C / 73°F – 140°F
Manufacturing Standards
AWWA C901, C906; ASME B16.40; ASTM D2513, D3261, D3350; ISO 4437-4; EN 1555-4; EN 12201-4; NSF 61 & 372
Testing Standards
ASME B16.40, AWWA C521, EN 28233, ISO 1167, ISO 11357-6, etc.
Material Benefits
- High tensile and impact strength
- Excellent chemical and corrosion resistance
- Long service life with low maintenance
- Recyclable and environmentally safe
- Ideal for high-pressure gas and water applications
Applications
We offer a full range of resources to support our partners. Access product catalogs, step-by-step installation guides, and training videos ensure proper installation and use of HDPE fittings and systems.
Data centers (LIQUID cooling systems)
Gas distribution networks
Industrial and municipal water systems
